Figure 53: Example of using two cursors

When using two cursors, the Statistics feature will calculate
statistics according to the data set between the two cursors.
To display the first cursor:
st
Click 1 Cursor
cursor with the mouse onto any other point on the plot, or onto
a different plot. For finer cursor movements use the forward
and backward keys on the keyboard.
The coordinate values of the selected point will appear in the
information bar at the bottom of the graph window.
To display the second cursor:
nd
Click 2 Cursor
any other point on the plot. The information bar will now
display the difference between the two coordinate values.
on the graph toolbar. You can drag the
and drag the cursor with the mouse onto
163
