Menu/Enter button
Use to enter logger menu options and to execute logger
commands.
Scroll button
Use to scroll though menu items and to power on unit.
3.1.2.

DNL804, DNL808 and DNL810

The Mini DataNet logger models have the same front panel
design.

Figure 19: DNL808 data logger front panel

Multi-function button: Use to execute logger commands.
Dual–color LED indicator: Indicates status of logger such as
joining network, leaving network, etc.
Multi-function Multi-function Multi-function
button button button
Dual-color Dual-color
LED indicator LED indicator
