3.16.4. Additional Repeater Screens

Unit Beep
When the DataNet software activates the Call Unit feature, the
Repeater will beep and the following screen will be displayed:
Beep Unit
Fourier Systems
Refer to section 4.11.3 for more details.
No Parent Signal/No Parent Found
When a Repeater's parent unit, such as another Repeater or
the Receiver, goes offline then the following screen is
immediately displayed on the logger:
No Parent signal
For example, this could happen if the Receiver managing the
network has formed a new network, so there is no Receiver
managing the previous network. Or if the parent unit is a
Repeater, and it goes offline, then this Repeater will display
the message above.
Once it has determined that the parent signal is lost, it will try
to establish a connection with the network via another
Repeater but if it fails then the following screen is displayed:
Fourier Systems
No Parent found
92
