Chapter 2:
DataNet
Implementation Guide
Fourier Systems strongly suggests first time users of the
DataNet system read this chapter before drilling down into the
many features of the system described later in the user guide.
The Implementation Guide will give you a clear understanding
of the basic aspects of setting up the system, and getting your
network up and running.
Once you are familiar with the technical aspects of setting up
the network as outlined in this chapter, please consult section
2.8 2.9 for Fourier's recommended approach to initial
deployment of the system.
Example
Below is a diagram depicting a supermarket deployment of a
DataNet system, illustrating how the devices may be
positioned to provide full coverage within the facility.
Figure 2: Example of DataNet network application
