DNL804
Sensor
Current
DNL808
Sensor
Temperature NTC
10 KΩ
3.7.3.
Connect the sensor/s to the terminal block/s at the top of data
logger:

Figure 27: DataNet logger sensor inputs

Sensors do not have to be added successively. You may only
configure In-4, or configure In-1 and In-3, for example, when
setting up the logger via the software.
Measurement
Range
4 to 20 mA
Measurement
Range
-50 to 150 ºC

Sensor Connection

Accuracy
0.5 %
Accuracy
-50 to 60 ˚C: ±0.3 ˚C
60 to 150 ˚C: ±0.5 %
50
