2. Select the Style tab, and unselect the Use system line
properties checkbox.
3. Select the axis you want to format in the Axis drop-down
menu.
4. Select the color and line width.
5. Click OK.
6. To restore the default formatting, select the Use system
line properties checkbox again.
Manual Scaling
1. Click Graph properties
the Graph properties dialog.
2. Select the Axis Scaling tab and with the Group plots by
units checkbox unselected, select the axis to manually
scale from the drop-down menu e.g. Date & Time axis.
3. Uncheck the Autoscale check box and enter the custom
values in the text box i.e. a time range, in the case of the
Time & Date axis, or a set of values.
4. Click OK.
5. To restore auto scaling select the Autoscale checkbox.
Manual Scaling - Grouping Plots by Unit
You may choose to group all of the sensors measuring the
same unit, to the same scale. For example, if you have
several temperature sensors in your data set, all measuring
Celsius, you can apply a common scale when displaying the
data from these sensors.
1. Click Graph properties
the Graph properties dialog.
on the graph toolbar to open
on the graph toolbar to open
