display the update progress. When complete the main logger
status screen will be displayed.
Also refer to Chapter 5: Updating DataNet Software and
Firmware.
Loading firmware
Progress: 55%
Note: Logger must be in Stop mode before firmware can be
updated.
3.13. Operating the Mini DataNet
DNL804, DNL808 and
DNL810
This section explains how to operate the DNL804, DNL808
and DNL810 Mini DataNet units using the multi-functional
button on the logger front panel. There is no LCD screen on
the Mini DataNet models.
Ensure the device Serial Number has been added to the
Device Filter before continuing. Refer to section 2.5.3.

3.13.1. Turning the Units Off and On

To conserve battery, the Mini DataNet LED does not provide
an indication of on/off status. If you wish to operate the logger
it is best to first be sure the unit is turned off before continuing.
Turning the Unit Off
1. Press and hold the logger button until the LED emits a
fixed, red light.
2. Release the logger button. The LED will then blink red
three times and switch off.
76
