Displaying Port Members of Multicast Services

You can display the port members associated with a specified VLAN and
multicast IP address.
Command Attribute
• VLAN ID – Selects the VLAN in which to display port members.
• Multicast IP Address – The IP address for a specific multicast service
• Multicast Group Port List – Ports propagating a multicast service;
i.e., ports that belong to the indicated VLAN group.
Web – Click IGMP/IP Multicast Registration Table. Select the VLAN ID
and multicast IP address. The switch will display all the ports that are
propagating this multicast service.
CLI – This example displays all the known multicast services supported
on VLAN 1, along with the ports propagating the corresponding services.
The type field shows if this entry was learned dynamically or was statically
configured.
Console#show bridge 1 multicast vlan 1
VLAN M'cast IP addr. Member ports Type
---- --------------- ------------ -------
1 224.0.0.12
1 224.1.2.3
Console#
Eth1/12 USER
Eth1/12 IGMP
