6.4.9 8-** Comm. and Options

Par. No. # Parameter description
8-0* General Settings
8-01 Control Site
8-02 Control Source
8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout
8-07 Diagnosis Trigger
8-08 Readout Filtering
8-1* Control Settings
8-10 Control Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Maximum Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram Selection
8-42 PCD Write Configuration
8-43 PCD Read Configuration
8-5* Digital/Bus
8-50 Coasting Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-7* BACnet
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "I-Am" Service
8-75 Initialisation Password
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Message Rcvd
8-83 Slave Error Count
VLT AQUA Low Harmonic Drive Operating Instructions
Default value
null
null
ExpressionLimit
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
null
[0] FC profile
[1] Profile Default
[1] Profile default
[0] FC
ExpressionLimit
null
null
ExpressionLimit
ExpressionLimit
ExpressionLimit
[1] Standard telegram 1
ExpressionLimit
ExpressionLimit
[3] Logic OR
[3] Logic OR
[3] Logic OR
null
[3] Logic OR
[3] Logic OR
1 N/A
127 N/A
1 N/A
[0] Send at power-up
ExpressionLimit
0 N/A
0 N/A
0 N/A
0 N/A
®
MG20T202 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion
operation index
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE -1
1 set-up TRUE -
1 set-up TRUE -
All set-ups TRUE -
2 set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE -
1 set-up TRUE 0
1 set-up TRUE -
1 set-up TRUE -
1 set-up TRUE -3
1 set-up TRUE -3
1 set-up TRUE -5
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
1 set-up TRUE 0
1 set-up TRUE 0
1 set-up TRUE 0
1 set-up TRUE -
1 set-up TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
Type
Uint8
Uint8
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
6 6
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
Uint8
Uint16
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint32
Uint8
Uint16
Uint8
VisStr[2
0]
Uint32
Uint32
Uint32
Uint32
111
