6.3.4 5-1* Digital Inputs
Parameters for configuring the input functions for the
input terminals.
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
DC-brake inverse
Stop inverse
External interlock
6 6
Start
Latched start
Reversing
Start reversing
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Pulse input
Ramp bit 0
Mains failure inverse
Run Permissive
Hand start
Auto start
DigiPot Increase
DigiPot Decrease
DigiPot Clear
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
Sleep Mode
Reset Maintenance Word
Lead Pump Start
Lead Pump Alternation
Pump 1 Interlock
Pump 2 Interlock
Pump 3 Interlock
All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/
are the terminals on MCB 101.
82
VLT AQUA Low Harmonic Drive Operating Instructions
The digital inputs are used for selecting various functions
in the frequency converter. All digital inputs can be set to
the following functions:
Select
[0]
[1]
[2]
[3]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[32]
[34]
[36]
[52]
[53]
[54]
[55]
[56]
[57]
[60]
[61]
[62]
[63]
[64]
[65]
[66]
[78]
[120]
[121]
[130]
[131]
[132]
Functions dedicated to only one digital input are stated in
the associated parameter.
®
MG20T202 - VLT is a registered Danfoss trademark
Terminal
All *term 32, 33
All
All
All
All
All
All
All *term 18
All
All *term 19
All
All *term 29
All
All
All
All
All
All
All
All
All
All
term 29, 33
All
All
All
All
All
29, 33
29, 33
All
29, 33
29, 33
All
