3 Introduction to the Low Harmonic Drive

3.1.1 Working Principle

3 3
The VLT Low Harmonic Drive is a VLT High Power
frequency converter with an integrated active filter. An
active filter is a device that actively monitors harmonic
Mains
Optional
380 to
RFI
500 VAC
Illustration 3.1 Basic Layout for the Low Harmonic Drive

3.1.2 IEEE519 Compliance

Low harmonic drives are designed to draw an ideal
sinusoidal current waveform from the supply grid with a
power factor of 1. Where traditional non linear load draws
pulse shaped currents the low harmonic drive
compensates that via the parallel filter path lowering the
stress on the supply grid. The Low harmonic drive meets
the toughest harmonic standards and has a THiD of less
than 5% at full load for <3% pre-distortion on a 3%
unbalanced three-phased grid. The unit is designed to
meet IEEE519 recommendation for Isc/Il >20 for both
uneven and even individual harmonic levels. The filter
portion of the low harmonic drives has a progressive
switching frequency which leads to a wide frequency
spreads giving lower individual harmonic levels above the
50th.
12
VLT AQUA Low Harmonic Drive Operating Instructions
HI Reactor
L
m
L
ac
L
Optional m
Optional
Manual
Fuses
Disconnect
L
ac
L
m
L
ac
MG20T202 - VLT
distortion levels and injects compensative harmonic
current onto the line to cancel out the harmonics.
Relay 12
Control & AUX
Feedback
Soft-Charge
NC
Relay
AC
Contactor
Relay 12
Control & AUX
C C C
ef ef ef
Feedback
R R R
ef ef ef
3
Main's
10
9
8
7
6
I [%]
5
4
3
2
1
0
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
Illustration 3.2 Typical harmonic frequency spectrum and THD
value at the mains terminals of the frequency converter
n = harmonic order
⃟.....IEEE519 (Isc/IL>20) limits for individual harmonics
®
is a registered Danfoss trademark
Converter
Power Stage
Side Filter
L I
c r
L I
c s
L I
c t
3
3
Capacitor
AF Current
Current Sensors
Sensors
Frequency converter
CTs
[n]
