6.1.5 Q5 Changes Made
Q5 Changes Made can be used for fault finding.
Select Changes made to get information about:
•
the last 10 changes. Use the up/down navigation
keys to scroll between the last 10 changed
parameters.
•
the changes made since default setting.
Select Loggings to get information about the display line
read-outs. The information is shown as graphs.
Only display parameters selected in 0-20 Display Line 1.1
Small and 0-24 Display Line 3 Large can be viewed. It is
possible to store up to 120 samples in the memory for
6 6
later reference.
Note that the parameters listed in the below tables for Q5
only serve as examples as they will vary depending on the
programming of the particular frequency converter.
20-94 PID Integral Time
20-93 PID Proportional Gain
20-93 PID Proportional Gain
20-94 PID Integral Time
Analog Input 53
Analog Input 54
6.1.6 Q6 Loggings
Q6 Loggings can be used for fault finding.
Notice that the parameters listed in the below table for Q6
only serve as examples as they will vary depending on the
programming of the particular frequency converter.
Reference
Analog Input 53
Motor Current
Frequency
Feedback
Energy Log
Trending Cont Bin
Trending Timed Bin
Trending Comparison
70
VLT AQUA Low Harmonic Drive Operating Instructions
Q5-1 Last 10 Changes
Q5-2 Since Factory Setting
Q5-3 Input Assignments
Q6 Loggings
MG20T202 - VLT
6.1.7 Main Menu Mode
Both the GLCP and NLCP provide access to the main menu
mode. Select the Main Menu mode by pressing the [Main
Menu] key. Illustration 6.2 shows the resulting read-out,
which appears on the display of the GLCP.
Lines 2 through 5 on the display show a list of parameter
groups which can be chosen by toggling [
Illustration 6.2 Display Example
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu. The
configuration of the unit (1-00 Configuration Mode) will
determine other parameters available for programming.
For example, selecting [3] Closed Loop enables additional
parameters related to closed loop operation. Option cards
added to the unit enable additional parameters associated
with the option device.
6.1.8 Parameter Selection
In the Main Menu mode, the parameters are divided into
groups. Select a parameter group by means of the
navigation keys.
®
is a registered Danfoss trademark
▲
] and [
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
▼
].
1 (1)
