Danfoss VLT AQUA Drive FC 200 Operating Instructions Manual page 77

How to Programme the Low Ha...
0-20 Display Line 1.1 Small
Option:
[3409] PCD 9 Write to
MCO
[3410] PCD 10 Write to
MCO
[3421] PCD 1 Read from
MCO
[3422] PCD 2 Read from
MCO
[3423] PCD 3 Read from
MCO
[3424] PCD 4 Read from
MCO
6 6
[3425] PCD 5 Read from
MCO
[3426] PCD 6 Read from
MCO
[3427] PCD 7 Read from
MCO
[3428] PCD 8 Read from
MCO
[3429] PCD 9 Read from
MCO
[3430] PCD 10 Read from
MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded
Position
[3452] Actual Master
Position
[3453] Slave Index Position
[3454] Master Index
Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master
Velocity
[3460] Synchronizing
Status
[3461] Axis Status
[3462] Program Status
[3464] MCO 302 Status
[3465] MCO 302 Control
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
[4285] Active Safe Func.
[4286] Safe Option Info
[9913] Idle time
[9914] Paramdb requests
in queue
76
VLT AQUA Low Harmonic Drive Operating Instructions
Function:
®
MG20T202 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option: Function:
[9917] tCon1 time
[9918] tCon2 time
[9919] Time Optimize
Measure
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1,
middle position.
[1662] Analog input The options are the same as those
*
53 listed for 0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1,
right position.
[1614] Motor Current The options are the same as those listed
*
for 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1615] Frequency The options are the same as those listed for
*
par. 0-20 Display Line 1.1 Small
0-24 Display Line 3 Large
Option: Function:
[1652] Feedback [Unit] The options are the same as those
*
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
