Danfoss VLT AQUA Drive FC 200 Operating Instructions Manual page 75

How to Programme the Low Ha...
0-20 Display Line 1.1 Small
Option:
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
*
[1602] Reference %
6 6
[1603] Status Word
[1605] Main Actual Value
[%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
*
[1618] Motor Thermal
[1619] KTY sensor
temperature
74
VLT AQUA Low Harmonic Drive Operating Instructions
Function:
View the mains power
consumption in kWh.
View the Control Word sent from
the frequency converter via the
serial communication port in hex
code.
Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in selected
unit.
Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in percent.
Present status word
One or more warnings in a Hex
code
View the user-defined readouts as
defined in 0-30 Custom Readout
Unit, 0-31 Custom Readout Min
Value and 0-32 Custom Readout
Max Value.
Actual power consumed by the
motor in kW.
Actual power consumed by the
motor in HP.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
Phase current of the motor
measured as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
Present motor load as a
percentage of the rated motor
torque.
Speed in RPM (revolutions per
minute) i.e. the motor shaft speed
in closed loop based on the
entered motor nameplate data,
the output frequency and the load
on the frequency converter.
Thermal load on the motor,
calculated by the ETR function.
See also parameter group 1-9*
Motor Temperature.
®
MG20T202 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option: Function:
[1620] Motor Angle
[1621] Torque [%] High
Res.
[1622] Torque [%] Shows the actual torque
produced, in percentage.
[1625] Torque [Nm] High
[1630] DC Link Voltage Intermediate circuit voltage in the
frequency converter.
[1632] Brake Energy /s Present brake power transferred to
an external brake resistor.
Stated as an instantaneous value.
[1633] Brake Energy /2 Brake power transferred to an
min external brake resistor. The mean
power is calculated continuously
for the most recent 120 seconds.
[1634] Heatsink Temp. Present heat sink temperature of
the frequency converter. The cut-
out limit is 95 ±5 oC; cutting back
in occurs at 70 ±5° C.
[1635] Inverter Thermal Percentage load of the inverters
[1636] Inv. Nom. Current Nominal current of the frequency
converter
[1637] Inv. Max. Current Maximum current of the frequency
converter
[1638] SL Controller State State of the event executed by the
control
[1639] Control Card Temp. Temperature of the control card.
[1650] External Reference Sum of the external reference as a
percentage, i.e. the sum of analog/
pulse/bus.
[1651] Pulse Reference
[1652] Feedback [Unit] Signal value in units from the
programmed digital input(s).
[1653] Digi Pot Reference View the contribution of the
digital potentiometer to the actual
reference Feedback.
[1657] Feedback [RPM]
[1660] Digital Input Displays the status of the digital
inputs. Signal low = 0; Signal high
= 1.
Regarding order, see 16-60 Digital
Input. Bit 0 is at the extreme right.
[1661] Terminal 53 Switch Setting of input terminal 53.
Setting Current = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as
a reference or protection value.
[1663] Terminal 54 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
