How to Install
Frame size
IP
Enclosure protection
NEMA
Normal overload rated power - 110%
overload torque
Drive Dimensions Height
Width
Depth
Max Weight
Shipping
Weight
Frame size
Enclosure protection
Normal overload rated power - 110% overload
torque
Drive Dimensions
VLT AQUA Low Harmonic Drive Operating Instructions
Mechanical Dimensions and Rated Power
D13
21/54
Type 1/Type 12
160Æ-250 kW at 400 V
(380-480 V)
1780.5 mm/70.1"
1021.9 mm/40.23"
377.8 mm/14.87"
390 kg/860 lbs.
435 kg/959 lbs.
IP
NEMA
Height
Width
Depth
Max Weight
Shipping
Weight
®
MG20T202 - VLT is a registered Danfoss trademark
E9
21/54*
Type 1/Type 12
315-450 kW at 400 V
(380-480 V)
2000.7 mm/78.77"
1200 mm/47.24"
493.5 mm/19.43"
676 kg/1490 lbs.
721 kg/1590 lbs.
F18
21/54
Type 1
500-710 kW at 400 V
(380-480 V)
2278.4 mm/89.70"
2792 mm/109.92"
605.8 mm/23.85"
1900 kg/4189 lbs.
2262 kg/4987 lbs.
4 4
