General Specifications
Mains Supply 3x380-480 VAC
High/ Normal Load*
Typical Shaft output at
400 V [kW]
Typical Shaft output at
460 V [HP]
Typical Shaft output at
480 V [kW]
Enclosure IP21
Enclosure IP54
Output current
Continuous
(at 400 V) [A]
Intermittent (60 s
overload)
(at 400 V) [A]
Continuous
(at 460/ 480 V) [A]
Intermittent (60 s
overload)
(at 460/ 480 V) [A]
Continuous KVA
(at 400 V) [KVA]
Continuous KVA
(at 460 V) [KVA]
Continuous KVA
(at 480 V) [KVA]
Max. input current
Continuous
(at 400 V ) [A]
Continuous
(at 460/ 480 V) [A]
Max. cable size, mains,
motor and load share
[mm 2 (AWG
Max. cable size, brake
2
[mm (AWG
Max. external mains
fuses [A]
Estimated motor power
loss
at 400 V [W]
Estimated motor power
loss
at 460 V [W]
Estimated filter losses,
400 V
Estimated filter losses,
460 V
Weight,
enclosure IP21, IP54 [kg]
Efficiency
Output frequency
Heatsink overtemp. trip
Power card ambient trip
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
VLT AQUA Low Harmonic Drive Operating Instructions
P250
HO NO
250 315
350 450
315 355
E9
E9
480 600
720 660
443 540
665 594
333 416
353 430
384 468
472 590
436 531
4x240
(4x500 mcm)
2) )]
2x185
2) (2x350 mcm)
)
700
1
6704
4)
5930
6607
6670
596
4)
®
MG20T202 - VLT is a registered Danfoss trademark
P315 P355
HO NO HO
315 355 355
450 500 500
355 400 400
E9 E9
E9 E9
600 658 658
900 724 987
540 590 590
810 649 885
416 456 456
430 470 470
468 511 511
590 647 647
531 580 580
4x240 4x240
(4x500 mcm) (4x500 mcm)
2x185 2x185
(2x350 mcm) (2x350 mcm)
900 900
7528 8671
6724 7820
7049 7725
7023 7697
623 646
0.96
0-600 Hz
110° C
68° C
P400
NO HO NO
400 400 450
600 550 600
500 500 530
E9
E9
745 695 800
820 1043 880
678 678 730
746 1017 803
516 482 554
540 540 582
587 587 632
733 684 787
667 667 718
4x240
(4x500 mcm)
2x185
(2x350 mcm)
900
9469
8527
8234
8099
646
151
8 8
