0-20 Display Line 1.1 Small
Option:
[1664] Analog Input 54 Actual value at input 54 either as
reference or protection value.
[1665] Analog Output 42 Actual value at output 42 in mA.
[mA] Use 6-50 Terminal 42 Output to
select the variable to be
represented by output 42.
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Freq. Input #29 [Hz] Actual value of the frequency
applied at terminal 29 as a pulse
input.
[1668] Freq. Input #33 [Hz] Actual value of the frequency
applied at terminal 33 as a pulse
input.
[1669] Pulse Output #27 Actual value of pulses applied to
[Hz] terminal 27 in digital output
mode.
[1670] Pulse Output #29 Actual value of pulses applied to
[Hz] terminal 29 in digital output
mode.
[1671] Relay Output [bin] View the setting of all relays.
[1672] Counter A View the present value of Counter
A.
[1673] Counter B View the present value of Counter
B.
[1674] Prec. Stop Counter
[1675] Analog In X30/11 Actual value of the signal on input
X30/11 (General Purpose I/O Card.
Option)
[1676] Analog In X30/12 Actual value of the signal on input
X30/12 (General Purpose I/O Card.
Optional)
[1677] Analog Out X30/8 Actual value at output X30/8
[mA] (General Purpose I/O Card.
Optional) Use 6-60 Terminal X30/8
Output to select the variable to be
shown.
[1678] Analog Out X45/1
[mA]
[1679] Analog Out X45/3
[mA]
[1680] Fieldbus CTW 1 Control word (CTW) received from
the Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with
control word via the serial
communications network e.g. from
the BMS, PLC or other master
controller.
[1684] Comm. Option STW Extended fieldbus communication
option status word.
VLT AQUA Low Harmonic Drive Operating Instructions
Function:
®
MG20T202 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option: Function:
[1685] FC Port CTW 1 Control word (CTW) received from
the Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus
Master.
[1690] Alarm Word One or more alarms in a Hex code
(used for serial communications)
[1691] Alarm Word 2 One or more alarms in a Hex code
(used for serial communications)
[1692] Warning Word One or more warnings in a Hex
code (used for serial communi-
cations)
[1693] Warning Word 2 One or more warnings in a Hex
code (used for serial communi-
cations)
[1694] Ext. Status Word One or more status conditions in a
Hex code (used for serial
communications)
[1836] Analog Input X48/2
[mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
[1890] Process PID Error
[1891] Process PID Output
[1892] Process PID
Clamped Output
[1893] Process PID Gain
Scaled Output
[3019] Wobble Delta Freq.
Scaled
[3110] Bypass Status Word
[3111] Bypass Running
Hours
[3401] PCD 1 Write to
MCO
[3402] PCD 2 Write to
MCO
[3403] PCD 3 Write to
MCO
[3404] PCD 4 Write to
MCO
[3405] PCD 5 Write to
MCO
[3406] PCD 6 Write to
MCO
[3407] PCD 7 Write to
MCO
[3408] PCD 8 Write to
MCO
