6.4.6 4-** Limits/Warnings

Par. No. # Parameter description
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
4-19 Max Output Frequency
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up
VLT AQUA Low Harmonic Drive Operating Instructions
Default value
[0] Clockwise
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
100.0 %
ExpressionLimit
ExpressionLimit
0.00 A
ImaxVLT (P1637)
0 RPM
outputSpeedHighLimit
(P413)
-999999.999 N/A
999999.999 N/A
-999999.999 Reference-
FeedbackUnit
999999.999 Reference-
FeedbackUnit
[2] Trip 1000 ms
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
®
