NOTE
When set for Closed Loop, the commands Reversing and
Start Reversing will not reverse the direction of the motor.
NOTE
1-20 Motor Power [kW], 1-21 Motor Power [HP], 1-22 Motor
Voltage and 1-23 Motor Frequency will not have effect
when 1-10 Motor Construction = [1] PM, non salient SPM.
1-20 Motor Power [kW]
Range:
Size [
related 3000.00
*
6 6 kW]
1-22 Motor Voltage
Range:
Size
related 1000. V]
*
1-23 Motor Frequency
Range:
Size [20 -
related 1000 Hz]
*
NOTE
This parameter cannot be changed while the motor is
running.
1-24 Motor Current
Range:
Size
related 10000.00 A]
*
78
Function:
0.09 - Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the unit.
This parameter cannot be adjusted
while the motor is running. Depending
on the choices made in 0-03 Regional
Settings, either 1-20 Motor Power [kW] or
1-21 Motor Power [HP] is made invisible.
Function:
[ 10. - Enter the nominal motor voltage
according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted
while the motor is running.
Function:
Select the motor frequency value from
the motor nameplate data. For 87 Hz
operation with 230/400 V motors, set the
nameplate data for 230 V/50 Hz. Adapt
4-13 Motor Speed High Limit [RPM] and
3-03 Maximum Reference to the 87 Hz
application.
Function:
[ 0.10 - Enter the nominal motor current
value from the motor nameplate
data. This data is used for
calculating motor torque, motor
thermal protection etc.
MG20T202 - VLT
VLT AQUA Low Harmonic Drive Operating Instructions
NOTE
This parameter cannot be changed while the motor is
running.
1-25 Motor Nominal Speed
Range:
Size related
NOTE
This parameter cannot be changed while the motor is
running.
1-29 Automatic Motor Adaptation (AMA)
Option:
[0] Off
*
[1] Enable
complete
AMA
[2] Enable
reduced AMA
NOTE
1-29 Automatic Motor Adaptation (AMA) will not have effect
when 1-10 Motor Construction = [1] PM, non salient SPM.
Activate the AMA function by pressing [Hand On] after
selecting [1] Enable complete AMA or [2] Enable reduced
AMA. See also the item Automatic Motor Adaptation in the
Design Guide. After a normal sequence, the display will
read: "Press [OK] to finish AMA". After pressing the [OK]
key the frequency converter is ready for operation.
®
is a registered Danfoss trademark
Function:
[100 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
Function:
The AMA function optimizes dynamic motor
performance by automatically optimizing the
advanced motor 1-30 Stator Resistance (Rs) to
1-35 Main Reactance (Xh)) while the motor is
stationary.
No function
Performs AMA of the stator resistance R
the rotor resistance R , the stator leakage
r
reactance X , the rotor leakage reactance X
1
and the main reactance X
Performs a reduced AMA of the stator
resistance R in the system only. Select this
s
option if an LC filter is used between the
frequency converter and the motor.
,
S
2
.
h
