6.3 VLT AQUA Drive - Description of
Common Parameters

6.3.1 Main Menu

The Main Menu includes all available parameters in the
®
VLT AQUA Drive FC 200 frequency converter.
All parameters are grouped in a logic way with a group
name indicating the function of the parameter group.
All parameters are listed by name and number in
6.4 Parameter Options.
All parameters included in the Quick Menus (Q1, Q2, Q3,
Q5 and Q6) can be found in the following.
Some of the most used parameters for VLT
applications are also explained in the following section.
For a detailed explanation of all parameters, refer to the
®
VLT AQUA Drive Programming Guide MG20OXYY which is
available on www.danfoss.com or by ordering at the local
Danfoss office.
Parameters related to the fundamental functions of the
frequency converter, function of the LCP keys and configu-
ration of the LCP display.
0-01 Language
Option: Function:
Defines the language to be used in the
display.
The frequency converter can be delivered
with 4 different language packages.
English and German are included in all
packages. English cannot be erased or
manipulated.
[0] English Part of Language packages 1 - 4
*
[1] German Part of Language packages 1 - 4
[2] French Part of Language package 1
[3] Danish Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italian Part of Language package 1
[6] Swedish Part of Language package 1
[7] Dutch Part of Language package 1
[10] Chinese Language package 2
[20] Finnish Part of Language package 1
[22] English US Part of Language package 4
[27] Greek Part of Language package 4
[28] Portuguese Part of Language package 4
[36] Slovenian Part of Language package 3
[39] Korean Part of Language package 2
[40] Japanese Part of Language package 2
[41] Turkish Part of Language package 4
[42] Traditional Part of Language package 2
Chinese
[43] Bulgarian Part of Language package 3
VLT AQUA Low Harmonic Drive Operating Instructions
0-01 Language
Option:
[44] Serbian
[45] Romanian
[46] Hungarian
[47] Czech
[48] Polish
[49] Russian
[50] Thai
[51] Bahasa
0-20 Display Line 1.1 Small
Option:
®
AQUA Drive
[0]
[9]
[15]
[37]
[38]
[39]
[748]
[953]
[1005]
[1006]
[1007]
[1013]
[1230]
[1472]
[1473]
[1474]
[1501]
®
MG20T202 - VLT is a registered Danfoss trademark
Function:
Part of Language package 3
Part of Language package 3
Part of Language package 3
Part of Language package 3
Part of Language package 4
Part of Language package 3
Part of Language package 2
Part of Language package 2
Indonesian
Function:
Select a variable for display in line
1, left position.
None No display value selected
Performance
Monitor
Readout: actual
setup
Display Text 1 Present control word
Display Text 2 Enables an individual text string to
be written, for display in the LCP
or to be read via serial communi-
cation.
Display Text 3 Enables an individual text string to
be written, for display in the LCP
or to be read via serial communi-
cation.
PCD Feed Forward
Profibus Warning Displays Profibus communication
Word warnings.
Readout Transmit View the number of CAN control
Error Counter transmission errors since the last
power-up.
Readout Receive View the number of CAN control
Error Counter receipt errors since the last power-
up.
Readout Bus Off View the number of Bus Off
Counter events since the last power-up.
Warning Parameter View a DeviceNet-specific warning
word. One separate bit is assigned
to every warning.
Warning Parameter
Legacy Alarm Word
Legacy Warning
Word
Leg. Ext. Status
Word
Running Hours View the number of running hours
of the motor.
