23-01 ON Action
Arra [10]
Option:
[37]
Set digital out F low
[38]
Set digital out A high
[39]
Set digital out B high
[40]
Set digital out C high
[41]
Set digital out D high
[42]
Set digital out E high
[43]
Set digital out F high
[60]
Reset Counter A
[61]
Reset Counter B
[80]
Sleep Mode
6
6
[90]
Set ECB Bypass Mode
[91]
Set ECB Drive Mode
[100] Reset Alarms
NOTE
For choices [32] - [43], see also parameter group 5-3*,
Digital Outputs and 5-4*, Relays.
23-02 OFF Time
Array [10]
Range:
Size
related
0 ]
*
23-03 OFF Action
Array [10]
Option:
[0]
Disabled
*
[1]
No action
[2]
Select set-up 1
[3]
Select set-up 2
[4]
Select set-up 3
[5]
Select set-up 4
[10]
Select preset ref 0
[11]
Select preset ref 1
[12]
Select preset ref 2
98
Function:
Function:
[
0 -
Sets the OFF time for the Timed Action.
NOTE
The frequency converter has no back
up of the clock function and the set
date/time will reset to default
(2000-01-01 00:00) after a power
down unless a Real Time Clock
module with back up is installed. In
0-79 Clock Fault it is possible to
program for a Warning in case clock
has not been set properly, e.g. after a
power down.
Function:
Select the action during OFF Time.
See 13-52 SL Controller Action for
descriptions of the options.
MG20T202 - VLT
VLT AQUA Low Harmonic Drive Operating Instructions
23-03 OFF Action
Array [10]
Option:
[13]
Select preset ref 3
[14]
Select preset ref 4
[15]
Select preset ref 5
[16]
Select preset ref 6
[17]
Select preset ref 7
[18]
Select ramp 1
[19]
Select ramp 2
[22]
Run
[23]
Run reverse
[24]
Stop
[26]
DC Brake
[27]
Coast
[32]
Set digital out A low
[33]
Set digital out B low
[34]
Set digital out C low
[35]
Set digital out D low
[36]
Set digital out E low
[37]
Set digital out F low
[38]
Set digital out A high
[39]
Set digital out B high
[40]
Set digital out C high
[41]
Set digital out D high
[42]
Set digital out E high
[43]
Set digital out F high
[60]
Reset Counter A
[61]
Reset Counter B
[80]
Sleep Mode
[90]
Set ECB Bypass Mode
[91]
Set ECB Drive Mode
[100] Reset Alarms
23-04 Occurrence
Array [10]
Option:
[0]
All days
*
[1]
Working days
[2]
Non-working days
[3]
Monday
[4]
Tuesday
[5]
Wednesday
[6]
Thursday
[7]
Friday
[8]
Saturday
[9]
Sunday
®
is a registered Danfoss trademark
Function:
Function:
Select which day(s) the Timed Action
applies to. Specify working/non-working
days in 0-81 Working Days,
0-82 Additional Working Days and
0-83 Additional Non-Working Days.
