6.3.9 29-** Water Application Functions
The group contains parameters used for monitoring water/
wastewater applications.
29-00 Pipe Fill Enable
Option: Function:
[0] Disabled Select Enabled to fill pipes at a user specified
*
rate.
[1] Enabled Select Enabled to fill pipes with a user specified
rate.
29-01 Pipe Fill Speed [RPM]
Range:
Size related [ par. 4-11 - par. 4-13 RPM]
*
29-02 Pipe Fill Speed [Hz]
Range:
Size related [ par. 4-12 - par. 4-14 Hz]
*
29-03 Pipe Fill Time
Range: Function:
0.00 s [0.00 - 3600.00 s] Set the specified time for pipe filling
*
of horizontal pipe systems.
29-04 Pipe Fill Rate
Range:
0.001 [0.001 -
ProcessCtrlUnit 999999.999
*
ProcessCtrlUnit]
29-05 Filled Setpoint
Range:
0.000 [-999999.999 -
ProcessCtrlUnit 999999.999
*
ProcessCtrlUnit]
VLT AQUA Low Harmonic Drive Operating Instructions
Function:
Function:
Function:
Specifies the filling rate in
units/second using the PI
controller. Filling rate units
are feedback units/second.
This function is used for
filling-up vertical pipe
systems but will always be
active when the filling-
time has expired, until the
pipe fill-set-point set in
29-05 Filled Setpoint is
reached.
Function:
Specifies the Filled Set-
point at which the Pipe
Fill Function will be
disabled and the PID
controller will take
control. This function can
be used both for
horizontal and vertical
pipe systems.
®
