3.1.3 Ordering Form Type Code

It is possible to design a VLT Low Harmonic Drive
according to the application requirements by using the
ordering number system.
1 2 3 4 5 6 7 8 9 10
F C - X 0 2 P X X 0
Product groups
1-3
Frequency converter series 4-6
Power rating
8-10
Phases
11
Mains Voltage
12
Enclosure
13-15
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter 16-17
Brake 18
Display (LCP)
19
Coating PCB
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24-27
Software language
28
A options 29-30
B options 31-32
C0 options, MCO 33-34
C1 options 35
C option software 36-37
D options 38-39
To order a VLT Low Harmonic Drive, type the letter "N" in
position 16 of the type code string. Not all choices/options
are available for each frequency converter variant. To verify
if the appropriate version is available, consult the Drive
Configurator on the Internet. For more information on the
options available, see the Design Guide.
VLT AQUA Low Harmonic Drive Operating Instructions
11 12 13 14 15 16 17 18 19
T 4 E 2 1 N 2 X
®
MG20T202 - VLT is a registered Danfoss trademark
20 21 22 23 24 25
G C X X X S X
26 27 28 29 - - 30
X X X X . . X
