Danfoss VLT AQUA Drive FC 200 Operating Instructions Manual page 120

How to Programme the Low Ha...
Par. No. # Parameter description
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Pulse Input #29 [Hz]
16-68 Pulse Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-75 Analog In X30/11
16-76 Analog In X30/12
16-77 Analog Out X30/8 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Ext. Status Word
16-95 Ext. Status Word 2
16-96 Maintenance Word
VLT AQUA Low Harmonic Drive Operating Instructions
Default value
0 N/A
[0] Current
0.000 N/A
[0] Current
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
®
MG20T202 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion
operation index
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
Type
Uint16
Uint8
Int32
Uint8
Int32
Int16
Int16
Int32
Int32
Int32
6 6
Int32
Uint16
Int32
Int32
Int32
Int32
Int16
V2
N2
V2
V2
N2
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
119
