6-20 Terminal 54 Low Voltage
Range:
0.07 V [ 0.00 - par.
*
6-21 V]
6-21 Terminal 54 High Voltage
Range:
10.00 V [ par. 6-20 -
*
10.00 V]
6 6
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 [-999999.999 -
*
999999.999 ]
6-50 Terminal 42 Output
Option:
[0] No operation
[100] Output freq. 0-100
[101] Reference Min-Max Minimum reference - Maximum
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
88
VLT AQUA Low Harmonic Drive Operating Instructions
Function:
Enter the low voltage value. This analog
input scaling value should correspond
to the low reference/feedback value, set
in 6-24 Terminal 54 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
Function:
Enter the analog input scaling
value that corresponds to the low
voltage/low current value set in
6-20 Terminal 54 Low Voltage and
6-22 Terminal 54 Low Current.
Function:
Enter the analog input scaling
value that corresponds to the
high voltage/high current value
set in 6-21 Terminal 54 High
Voltage and 6-23 Terminal 54 High
Current.
Function:
Select the function of Terminal 42
as an analog current output. A
motor current of 20 mA corresponds
to I .
max
0 - 100 Hz, (0-20 mA)
reference, (0-20 mA)
-200% to +200% of 20-14 Maximum
Reference/Feedb., (0-20 mA)
0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit (4-13 Motor
Speed High Limit [RPM] and
MG20T202 - VLT
6-50 Terminal 42 Output
Option:
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100
4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA 0 - Torque limit (4-16 Torque Limit
[135] Torq.0-nom
4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
*
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o.
4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
NOTE
Values for setting the Minimum Reference is found in open
loop 3-02 Minimum Reference and for closed loop
20-13 Minimum Reference/Feedb. - values for maximum
reference for open loop is found in 3-03 Maximum
Reference and for closed loop 20-14 Maximum Reference/
Feedb.
6-51 Terminal 42 Output Min Scale
Range:
0.00 % [0.00 -
*
200.00 %]
®
is a registered Danfoss trademark
Function:
4-14 Motor Speed High Limit [Hz]),
(0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100 Hz
Minimum Reference - Maximum
Reference
-200% to +200% of 20-14 Maximum
Reference/Feedb.
0 - Inverter Max. Current (16-37 Inv.
Max. Current)
Motor Mode)
0 - Motor rated torque
0 - Motor rated power
0 - Speed High Limit (4-13 and 4-14)
0 - 100%, (0-20 mA)
0 - 100%
0 - 100%, (0-20 mA)
0 - 100%
0 - 100%
0 - 100%
0 - 100%
Function:
Scale for the minimum output (0 or
4mA) of the analog signal at terminal 42.
Set the value to be the percentage of
the full range of the variable selected in
6-50 Terminal 42 Output.
