Operation keys
for local control are found at the bottom of the control
panel.
Hand
on
[Hand On]
enables control of the frequency converter via the GLCP.
[Hand On] also starts the motor, and it is now possible to
5 5
give the motor speed reference by means of the arrow
keys. The key can be [1] Enabled or [0] Disabled via
0-40 [Hand on] Key on LCP.
The following control signals will still be active when
[Hand On] is activated:
•
[Hand On] - [Off] - [Auto On]
•
Reset
•
Coasting stop inverse (motor coasting to stop)
•
Reversing
•
Set-up select lsb - Set-up select msb
•
Stop command from serial communication
•
Quick stop
•
DC brake
NOTE
External stop signals activated by means of control signals
or a serial bus will override a "start" command via the LCP.
[Off]
stops the connected motor (when pressed on the
frequency converter LCP) or the filter (when pressed on
the filter LCP). The key can be [1] Enabled or [0] Disabled
via 0-41 [Off] Key on LCP. If no external stop function is
selected and the [Off] key is inactive the motor can only
be stopped by disconnecting the mains supply.
[Auto On]
enables the frequency converter to be controlled via the
control terminals and/or serial communication. When a
start signal is applied on the control terminals and/or the
bus, the frequency converter will start. The key can be [1]
Enabled or [0] Disabled via 0-42 [Auto on] Key on LCP.
NOTE
[Auto On] must be pressed on the filter LCP.
NOTE
An active HAND-OFF-AUTO signal via the digital inputs has
higher priority than the control keys [Hand On] – [Auto
On].
62
VLT AQUA Low Harmonic Drive Operating Instructions
Auto
O Reset
on
MG20T202 - VLT
[Reset]
is used for resetting the frequency converter or filter after
an alarm (trip). The key can be [1] Enabled or [0] Disabled
via 0-43 [Reset] Key on LCP.
The parameter shortcut
can be carried out by holding down the [Main Menu] key
for 3 seconds. The parameter shortcut allows direct access
to any parameter.
5.1.3 Changing Data
1. Press [Quick Menu] or [Main Menu].
▲
2.
Use [ ] and [
3. Press [OK].
▲
4.
Use [ ] and [
5. Press [OK].
▲
6.
Use [ ] and [
setting. Or, to move to digits within a number,
use [◄] and [►]. Cursor indicates digit selected to
▲
change. [
decreases the value.
7. Press [Cancel] to disregard change, or press [OK]
to accept change and enter new setting.
5.1.4 Changing a Text Value
If the selected parameter is a text value, change the text
value by means of the [
▲
[ ] increases the value, and [
the cursor on the value to be saved and press [OK].
Illustration 5.5 Display Example.
®
