Video and Camera Cables

HDMI Monitor Cable

This cable connects the RealPresence Group system HDMI output to an HDMI monitor. It is HDMI to male
HDMI.
Length
6 ft (1.8 m)
P1
2
1
19
18
TMDS Data2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data1+
TMDS Data1 Shield
TMDS Data1-
TMDS Data0+
TMDS Data0 Shield
TMDS Data0-
TMDS Clock+
TMDS Clock Shield
TMDS Clock-
CEC
RESERVED
SCL
SDA
DDC/CEC GROUND
+5 Volts
Hot Plug Detect
Cable Shield
Note: Drawings and part numbers are provided for reference only. Polycom claims no responsibility or
liability for the quality, performance, or reliability of cables based on these reference drawings, other
than cables provided by Polycom. Contact your Polycom distributor or Polycom Custom/Vertical
Products to order cables that meet the appropriate manufacturing tolerances, quality, and performance
parameters for your application.
Polycom, Inc.
Part Number
2457-28808-004
WIRING LIST
SIGNAL P1 P2
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
SHELL SHELL
RoHS Compliant
Yes
1829.5±50
7.0 REF
SEE NOTE 7
CABLE
CONDUCTOR
UNIT
TIP
D1 DRAIN
RING
TIP
D2 DRAIN
RING
TIP
D3 DRAIN
RING
TIP
D4 DRAIN
RING
E1
E2
TIP
F
RING
E3
E4
E5
B
19
1
DETAIL A
SCALE 3.000
Cables
P2
18
2
