Chapter 5 Configuring the EM720
Client Enabled
Server IP Address
Server Port
Message Exchange
Address
Connection via Network
EM720 Power Quality and Revenue Meter
The following table lists available options.
Parameter
NO, YES
0-65535
0-65535
Ethernet,
GPRS/Modem
Client connections are triggered via programmable setpoints.
To send event notifications to a server, configure a setpoint
to respond to desired triggers or to periodic time events and
add the "Send notification" action to the end of the setpoint
actions list (see
Setpoint operation events triggered by regular analog and
digital triggers are reported twice - when the event starts and
when it ends, except of the pulsed events and time triggers
that will be reported once.
In case of triggering notifications with events generated by
the PQ and Fault recorders, like the PQ EVENT, FAULT EVENT,
EXTERNAL TRIGGER or FAULT DETECTED triggers, the
recorded power quality or/and corresponding fault events are
reported instead of setpoint-triggered notifications. If regular
triggers are added to the setpoint triggers list, then the
setpoint operation events will also be reported.
Configuring Communications
Options Default
NO
192.168.0.3
502
1000
Using Control Setpoints).
Description
Enables operations of the
notification client
The IP address of the
notification server
The TCP service port of the
notification server
Selects the network for
connecting to the
notification server
