Satec expertmeter EM720 Operation Manual page 200

Appendix D EN50160 Statistics Log Files
Field No.
8
9
10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
1
2
3
4
5
6
1
2
3
4
5
200
Designation
V2 Plt Max Maximum Plt on phase V2
V3 N1 Number of incidents Plt > 1% on phase V3
V3 Plt Max Maximum Plt on phase V3
N11 90%/100ms Number of polyphase incidents u<90%/t<100ms
N12 85%/100ms Number of polyphase incidents u<85%/t<100ms
N13 70%/100ms Number of polyphase incidents u<70%/t<100ms
N14 40%/100ms Number of polyphase incidents u<40%/t<100ms
N11 90%/500ms Number of polyphase incidents u<90%/t<500ms
N12 85%/500ms Number of polyphase incidents u<85%/t<500ms
N13 70%/500ms Number of polyphase incidents u<70%/t<500ms
N14 40%/500ms Number of polyphase incidents u<40%/t<500ms
N11 90%/1s Number of polyphase incidents u<90%/t<1s
N12 85%/1s Number of polyphase incidents u<85%/t<1s
N13 70%/1s Number of polyphase incidents u<70%/t<1s
N14 40%/1s Number of polyphase incidents u<40%/t<1s
N11 90%/3s Number of polyphase incidents u<90%/t<3s
N12 85%/3s Number of polyphase incidents u<85%/t<3s
N13 70%/3s Number of polyphase incidents u<70%/t<3s
N14 40%/3s Number of polyphase incidents u<40%/t<3s
N11 90%/20s Number of polyphase incidents u<90%/t<20s
N12 85%/20s Number of polyphase incidents u<85%/t<20s
N13 70%/20s Number of polyphase incidents u<70%/t<20s
N14 40%/20s Number of polyphase incidents u<40%/t<20s
N11 90%/60s Number of polyphase incidents u<90%/t<60s
N12 85%/60s Number of polyphase incidents u<85%/t<60s
N13 70%/60s Number of polyphase incidents u<70%/t<60s
N14 40%/60s Number of polyphase incidents u<40%/t<60s
N11 90%/180s Number of polyphase incidents u<90%/t<180s
N12 85%/180s Number of polyphase incidents u<85%/t<180s
N13 70%/180s Number of polyphase incidents u<70%/t<180s
N14 40%/180s Number of polyphase incidents u<40%/t<180s
V1 N1 Total number of incidents on phase V1
V1 Min Minimum residual voltage on phase V1
V2 N1 Total number of incidents on phase V2
V2 Min Minimum residual voltage on phase V2
V3 N1 Total number of incidents on phase V3
V3 Min Minimum residual voltage on phase V3
N1 1s Number of polyphase incidents t<1s
N2 180s Number of polyphase incidents t<180s
N3 >180s Number of polyphase incidents t>180s
V1 Min Minimum residual voltage on phase V1
V2 Min Minimum residual voltage on phase V2
V3 Min Minimum residual voltage on phase V3
N11 110%/1s Number of polyphase incidents u>110%/t<1s
N12 120%/1s Number of polyphase incidents u>120%/t<1s
N13 140%/1s Number of polyphase incidents u>140%/t<1s
N14 160%/1s Number of polyphase incidents u>160%/t<1s
N15 200%/1s Number of polyphase incidents u>200%/t<1s
Description
Voltage Dips (indicative statistics)
Voltage Interruptions (indicative statistics)
Temporary Overvoltages (indicative statistics)
EM720 Power Quality and Revenue Meter
