Chapter 4 Using PAS Software

Chapter 4 Using PAS Software

Software Installation

Installing PAS

PAS

Installing the USB Driver

48
The support PAS software is a configuration and data
acquisition tool that allows you to configure all of the EM720
features, monitor your meter on-line, retrieve recorded files
and view reports. PAS can communicate with your meter via
any communication
including the embedded infrared port, serial ports, and the
Ethernet and wireless GSM/GPRS communications.
This chapter gives information on how to install and run PAS
on your computer, and how to prepare information for your
meter using PAS. See Chapter 5
instructions on how to configure particular features in your
EM720. Refer to Chapters 7 and 8 for instructions on
retrieving data from your meter and viewing reports.
NOTE
PAS uses the Modbus RTU or Modbus TCP protocol for
communicating with the EM720. If you connect your PC to
the EM720 via s serial infrared or RS-232/RS-485 port,
ensure that the port is set to the Modbus RTU mode.
You need PAS V1.4 or higher to work with the EM720.
To install PAS on your PC:
1. Insert the installation CD supplied with your EM720
into CD drive.
2. Open My Computer on your Desktop.
3. Click on your CD drive icon, select the PAS directory,
and then double click on Setup (shown as an
Application type file).
4. Follow InstallShield®
screen.
PAS is installed by default to the C:\Program Files\Pas folder.
If your user account rights do not allow writing to the
C:\Program Files\ folder, change the PAS default installation
folder to another folder to avoid possible ODBC security
problems when running PAS.
When installation is complete, the PAS icon appears on your
Desktop. Double click on the PAS icon to run PAS.
For general information on how to work with PAS, see the
"PAS Getting Started" guide supplied on the installation CD.
To take an advantage of the USB communications, install the
EM720 USB driver on your PC.
EM720 Power Quality and Revenue Meter
Software Installation
interface installed
Configuring the EM720
Wizard instructions
in your meter,
for
on the
