Satec expertmeter EM720 Operation Manual page 139

Chapter 7 Monitoring Meters
Viewing a Data Table
Viewing Data Trend
Saving Data to a File
EM720 Power Quality and Revenue Meter
Changing the Data View
PAS displays data in either a single record or multi-record
view. To change the view, click on the Data Monitor window
with the right mouse button and select either Wrap to see a
single record, or UnWrap to go to the multi-record view.
Adjusting the Number of Rows in a Multi-Record View
Click the window with the right mouse button, select Options,
adjust the number of records you want to see in the window,
and then click OK. When the number of retrieved records
exceeds the number of rows in the window, the window
scrolls up so that older records are erased.
See Working with Tables
on working with tables.
To view a data trend, click on the
toolbar.
To change the time range for your graph, click on the
button on the local toolbar, and then select the desired date
and time range.
See Working with Graphic Windows
information on working with graphs.
To save retrieved data to a file for later analysis, click on the
Save button , select an existing database or type the
name for a new database, and then click Save.
To avoid confusion, do not store data files into the "Sites"
directory where site databases are located.
Viewing Real-time Data
in Chapter 9 for more information
button on the local
in Chapter 9 for more
139
