Instrumentation Metering - Satec expertmeter EM720 Operation Manual

Chapter 2 Operating the EM720
End of Billing
Billing Data Recording and Load Profiling
Billing Data Display

Instrumentation Metering

20
The present tariff rate is indicated on the EM720 display. If
required, tariff-switching
duration can be output via the meter relays.
The EM720 can be configured to trigger a reset of billing
maximum demands and an end of billing period automatically
on a monthly schedule, manually from the front display and
remotely via communications. It can also be done via control
setpoints using any programmable internal or external
trigger, like a specific time schedule or an external pulse.
You can select the reset sources via the Device Options setup
(see Device Options and Mode Control
The EM720 uses a one-day protection lockout time to avoid
multiple consecutive resets of the billing maximum demands.
The EM720 provides automatic recording of the billing data to
flash files:
• Monthly billing period data for the last 24 billing
periods
• Daily energy and maximum demand profile for the last
120 days
• 15-min energy load profile for 120 days or 30-min
profile for 240 days.
Maximum demand profiling for monthly and daily billing data
profiles can be individually configured for every register.
See Factory Preset Data Log Files
Load Profile Log Files
the file layout and contents.
The EM720 display
demand and cumulative maximum demand registers for the
present billing period and for three previous billing periods.
The display is automatically configured for your set of billing
registers and your tariff schedule. See
Displays in Chapter 3 for the display layout.
Instrumentation metering provides real-time measurements
and time-integration for local and remote power monitoring
and control, and a source for power quality evaluation and
triggering the logical controller and Fault recorder.
See Parameters for Monitoring and Logging
a full list of the electricity and status measurements provided
by the EM720.
All RMS quantities are based on 1/2-cycle true RMS
measurements as per IEC 61000-4-30.
EM720 Power Quality and Revenue Meter
Instrumentation Metering
pulses with
in Chapter 5).
in Chapter 5 and
in Appendix C for more information on
indicates billing
a programmable
Billing and
energy, maximum
Billing Period Data
in Appendix A for
