Chapter 5 Configuring the EM720
104
No.
1 V1/V12 Demand
2 V2/V23 Demand
3 V3/V31 Demand
4 I1 Demand
5 I2 Demand
6 I3 Demand
7 kW Import Sliding Demand
8 kvar Import Sliding Demand
9 KVA Sliding Demand
10 kWh Import
11 kWh Export
12 kvarh Import
13 kvarh Export
14 kVAh
15 In
16 Frequency
Data Log #13
Data Log #13 is linked to the Fault recorder and is configured
for fast 1/2-cycle RMS profiling of fault events. You can freely
manipulate this file, as you want. See
Recorder in Chapter 5 on how to enable or disable RMS
profiling and how to define the maximum duration of the fault
RMS profiles.
The factory pre-configured list of parameters for Data log
#13 is shown in the following table.
No.
1 1/2-cycle voltage V1/V12
2 1/2-cycle voltage V2/V23
3 1/2-cycle voltage V3/V31
4 1/2-cycle (neutral/zero-sequence) voltage V4
5 1/2-cycle current I1
6 1/2-cycle current I2
7 1/2-cycle current I3
8 1/2-cycle current I4
9 1/2-cycle zero-sequence voltage
Data Log #14
Data Log #14 is linked to the Power Quality recorder and is
configured for RMS profiling of power quality events. You can
freely manipulate this file. See
in Chapter 5 on how to enable or disable RMS profiling and
how to define the maximum duration and time envelopes for
the PQ RMS profiles.
The factory pre-configured list of parameters for Data log
#14 is shown in the following table. The time integration
interval for these parameters is dynamically changed as the
event continues for more time.
EM720 Power Quality and Revenue Meter
Configuring Recorders
Data Log #2
Parameter
Configuring the Fault
Data Log #13
Parameter
EN50160 PQ Recorder Setup
