Appendix A Parameters for Monitoring and Logging
Designation
kvar L1 H01
kvar L2 H01
kvar L3 H01
kVA L1 H01
kVA L2 H01
kVA L3 H01
PF L1 H01
PF L2 H01
PF L3 H01
HRM TOT POW
kW H01
kvar H01
kVA H01
PF H01
FLICKER
V1 Pst
V2 Pst
V3 Pst
V1 Plt
V2 Plt
V3 Plt
MIN PHASE
V1 MIN
V2 MIN
V3 MIN
I1 MIN
I2 MIN
I3 MIN
kW L1 MIN
kW L2 MIN
kW L3 MIN
kvar L1 MIN
kvar L2 MIN
kvar L3 MIN
kVA L1 MIN
kVA L2 MIN
kVA L3 MIN
PF L1 MIN
PF L2 MIN
PF L3 MIN
V1 THD MIN
V2 THD MIN
V3 THD MIN
I1 THD MIN
I2 THD MIN
I3 THD MIN
I1 KF MIN
I2 KF MIN
186
8
kvar L1
8
kvar L2
8
kvar L3
8
kVA L1
8
kVA L2
8
kVA L3
8
Power factor L1
8
Power factor L2
8
Power factor L3
Fundamental Total Power Values
8
Total fundamental kW
Total fundamental kvar
Total fundamental kVA
8
Total fundamental PF
Flicker
V1/V12 short-term (10 min) flicker severity
V2/V23 short-term (10 min) flicker severity
V3/V31 short-term (10 min) flicker severity
V1/V12 long-term (2 hours) flicker severity
V2/V23 long-term (2 hours) flicker severity
V3/V31 long-term (2 hours) flicker severity
Minimum 1-Cycle Phase Values
1
V1/V12 voltage
1
V2/V23 voltage
1
V3/V31 voltage
I1 current
I2 current
I3 current
8
kW L1
8
kW L2
8
kW L3
8
kvar L1
8
kvar L2
8
kvar L3
8
kVA L1
8
kVA L2
8
kVA L3
8
Power factor L1
8
Power factor L2
8
Power factor L3
2
V1/V12 voltage THD
2
V2/V23 voltage THD
2
V3/V31 voltage THD
I1 current THD
I2 current THD
I3 current THD
I1 K-Factor
I2 K-Factor
