Satec expertmeter EM720 Operation Manual page 197

Appendix C Billing and Load Profile Log Files
Field No.
24
25
26
27
Field No.
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
EM720 Power Quality and Revenue Meter
Designation
TRF7 CMD Tariff #7 cumulative max. demand
TRF8 MD Tariff #8 max. demand
TIME8 Tariff #8 max. demand timestamp
TRF8 CMD Tariff #8 cumulative max. demand
The number of parameters in each section is automatically
configured depending on the number of actual tariffs you
defined in the TOU Daily Profiles
Daily Billing Profile Data Log (Data Log #16)
Designation
REG1 Summary (total) energy reading
TRF1 Tariff #1 energy reading
TRF2 Tariff #2 energy reading
TRF3 Tariff #3 energy reading
TRF4 Tariff #4 energy reading
TRF5 Tariff #5 energy reading
TRF6 Tariff #6 energy reading
TRF7 Tariff #7 energy reading
TRF8 Tariff #8 energy reading
REG10 Summary (total) energy reading
TRF1 Tariff #1 energy reading
TRF2 Tariff #2 energy reading
TRF3 Tariff #3 energy reading
TRF4 Tariff #4 energy reading
TRF5 Tariff #5 energy reading
TRF6 Tariff #6 energy reading
TRF7 Tariff #7 energy reading
TRF8 Tariff #8 energy reading
REG1 MD Summary (total) max. demand reading
TRF1 MD Tariff #1 max. demand reading
TRF2 MD Tariff #2 max. demand reading
TRF3 MD Tariff #3 max. demand reading
TRF4 MD Tariff #4 max. demand reading
TRF5 MD Tariff #5 max. demand reading
TRF6 MD Tariff #6 max. demand reading
TRF7 MD Tariff #7 max. demand reading
TRF8 MD Tariff #8 max. demand reading
REG10 MD Summary (total) max. demand reading
TRF1 MD Tariff #1 max. demand reading
TRF2 MD Tariff #2 max. demand reading
TRF3 MD Tariff #3 max. demand reading
TRF4 MD Tariff #4 max. demand reading
TRF5 MD Tariff #5 max. demand reading
TRF6 MD Tariff #6 max. demand reading
Description
Description
Energy Register #1
...
Energy Register #10
Daily Maximum Demand Register #1
...
Daily Maximum Demand Register #10
