Chapter 2 Operating the EM720

Operating the Logical Controller

Operating the Event Recorder

Operating the EN50160 Power Quality Recorder

24
Each relay can be operated either locally from a control
setpoint in response to an internal or external event, or by a
remote command sent through communications, or can be
directly linked to an internal pulse source producing energy
or interval pulses.
See Configuring Relay Outputs
configure relay outputs in your meter.
See Using Control Setpoints
relay outputs via setpoints.
See Remote Relay Control
relays via PAS.
The embedded logical controller allows monitoring any
measured quantity or external contacts to provide indication,
counting and recording events whenever the value exceeds
the predefined threshold or when a status transition is
detected on the meter inputs. It provides a 1/2-cycle
response time for fast analog and digital triggers.
The controller can monitor internal diagnostic events and
meter operation status to give a fault indication via relay
outputs or provide cross triggering multiple devices.
All controller operations can be recorded to the meter Event
log with indication of the event time, source and a trigger
value.
See Using Control Setpoints
the meter logical controller for your application.
The Event recorder automatically records time-tagged self-
supervision events related to configuration changes, resets,
and device diagnostics.
It can also record setpoint-monitored events and setpoint
operations for setpoints individually configured for triggering
the Event recorder.
See Configuring the Event Recorder
information.
The EN 50160 Power
EN 50160 power quality statistics for EN 50160 compliance
reports, and long-term harmonics survey statistics for
trouble-shooting harmonic problems throughout an electrical
network. It also records time-tagged voltage disturbances
and voltage fault events into the Power Quality event log.
All power quality triggers have programmable thresholds and
can be adjusted for a specific application.
The PQ recorder is configurable for triggering the Waveform
recorder to record fault voltage and current waveforms
before, within and after an event, and can also trigger the
Data recorder for long-duration profiling of RMS voltages and
EM720 Power Quality and Revenue Meter
Operating the Logical Controller
in Chapter 5 on how to
in Chapter 5 on how to operate
in Chapter 6 on how to operate
in Chapter 5 on how to configure
in Chapter 5 for more
Quality (PQ) recorder provides
