Chapter 5 Configuring the EM720

EN50160 Advanced Setup

Option
Evaluation
Evaluation Period
First Day of the
Week
Evaluation
Evaluation Period
118
3. Download your setup to the device.
The default EN50160 compliance limits are shown in the
picture above. You can change the number of the evaluated
harmonics and interharmonics via the
Setup.
The EN50160 Advanced Setup allows you to configure the
EN50160 evaluation options in your meter.
To configure the EN50160 evaluation options:
1. Select Memory/Log from the Meter Setup menu, and
then click on the EN50160 Advanced Setup tab.
2. Change the EN50160 evaluation options if required.
3. Download your setup to the device.
The default EN50160 evaluation options set in your device
are shown in the picture below.
The available options are listed in the following table.
Range Default
EN50160 Compliance Statistics
Disabled, Enabled Enabled
Daily, Weekly Weekly
Sunday-Saturday Sunday
EN50160 Harmonics Survey
Disabled, Enabled Enabled
Daily, Weekly Weekly
Configuring the EN50160 Recorders
Enables the EN50160 evaluation
Defines the EN50160 statistics evaluation
period
Defines the first day of the week for
statistics evaluated on a weekly basis
Enables the harmonics survey log
Defines the harmonics survey evaluation
period
EM720 Power Quality and Revenue Meter
EN50160 Advanced
Description
