Satec expertmeter EM720 Operation Manual page 177

Appendix A Parameters for Monitoring and Logging
Designation
PF L3
V1 THD
V2 THD
V3 THD
I1 THD
I2 THD
I3 THD
I1 KF
I2 KF
I3 KF
I1 TDD
I2 TDD
I3 TDD
V12
V23
V31
RT LOW
V LOW
I LOW
kW LOW
kvar LOW
kVA LOW
PF LAG LOW
PF LEAD LOW
THD LOW
V THD LOW
KF LOW
I TDD LOW
V L-L LOW
RT HIGH
V HIGH
I HIGH
kW HIGH
kvar HIGH
kVA HIGH
PF LAG HIGH
PF LEAD HIGH
V THD HIGH
I THD HIGH
KF HIGH
I TDD HIGH
V L-L HIGH
RT TOTAL
kW
kvar
kVA
PF
PF LAG
EM720 Power Quality and Revenue Meter
8
Power factor L3
2,3
V1/V12 voltage THD
2,3
V2/V23 voltage THD
2,3
V3/V31 voltage THD
3
I1 current THD
3
I2 current THD
3
I3 current THD
3
I1 K-Factor
3
I2 K-Factor
3
I3 K-Factor
3
I1 current TDD
3
I2 current TDD
3
I3 current TDD
V12 voltage
V23 voltage
V31 voltage
1-Cycle Low Values on any Phase
Low line-to-neutral/line-to-line voltage
Low current
8
Low kW
8
Low kvar
8
Low kVA
8
Low lagging PF
8
Low leading PF
2,3
Low voltage THD
3
Low current THD
3
Low K-Factor
3
Low current TDD
Low line-to-line voltage
1-Cycle High Values on any Phase
High line-to-neutral/line-to-line voltage
High current
8
High kW
8
High kvar
8
High kVA
8
High PF Lag
8
High PF Lead
2,3
High voltage THD
3
High current THD
3
High K-Factor
3
High current TDD
High line-to-line voltage
1-Cycle Total Values
8
Total kW
8
Total kvar
8
Total kVA
8
Total PF
8
Total PF lag
Description
1
1
177
