Chapter 9 Viewing Files and Reports
Linking to Waveforms and Data Records
Retrieving Waveforms Online
156
If a setpoint is programmed for logging setpoint operation
events and it could trigger waveform or data recording, PAS
automatically establishes links between the event and other
database records where it finds a relationship with the event.
The event ID for which PAS found related data is blue
colored. Click on the colored ID to check a list of the event
links. Click on a list item to move to the related waveform or
data log record.
If you found an event for which you expect a waveform to be
recorded in the meter, but it has not yet been stored to the
database, you can retrieve it online.
Events for which PAS did not find a corresponding waveform
in the database are still black colored.
Click on the event ID, then click on the "Retrieve Waveform"
prompt and point to a database to which you want the
waveform to be stored.
EM720 Power Quality and Revenue Meter
Viewing the Event Log
