Satec expertmeter EM720 Operation Manual page 203

Appendix D EN50160 Statistics Log Files
Field No.
10
11
12
13
14
15
16
17
18
19
20
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Field No.
1
2
3
4
5
...
52
1
2
3
EM720 Power Quality and Revenue Meter
Designation
V1 H# Worst-case interharmonic component number on phase V1
V1 THD Max Worst-case interharmonic voltage THD on phase V1
V2 N1 Number of interharmonic voltage incidents on phase V2
V2 N2 Number of interharmonic voltage THD incidents on phase V2
V2 HD% Max Worst-case interharmonic magnitude on phase V2, %Un
V2 H# Worst-case interharmonic component number on phase V2
V2 THD Max Worst-case interharmonic voltage THD on phase V2
V3 N1 Number of interharmonic voltage incidents on phase V3
V3 N2 Number of interharmonic voltage THD incidents on phase V3
V3 HD% Max Worst-case interharmonic magnitude on phase V3, %Un
V3 H# Worst-case interharmonic component number on phase V3
V3 THD Max Worst-case interharmonic THD on phase V3
Nnv Number of non-valid 3-sec intervals
N Number of valid 3-sec intervals
N1 Number of polyphase incidents, N1
N1/N, % EN50160 compliance ratio, N1/N
V1 N1 Number of incidents on phase V1
V1 Frq1 %Un Maximum 1st signaling voltage magnitude on phase V1, %Un
V1 Frq2 %Un Maximum 2nd signaling voltage magnitude on phase V1, %Un
V1 Frq3 %Un Maximum 3rd signaling voltage magnitude on phase V1, %Un
V1 Frq4 %Un Maximum 4th signaling voltage magnitude on phase V1, %Un
V2 N1 Number of incidents on phase V2
V2 Frq1 %Un Maximum 1st signaling voltage magnitude on phase V2, %Un
V2 Frq2 %Un Maximum 2nd signaling voltage magnitude on phase V2, %Un
V2 Frq3 %Un Maximum 3rd signaling voltage magnitude on phase V2, %Un
V2 Frq4 %Un Maximum 4th signaling voltage magnitude on phase V2, %Un
V3 N1 Number of incidents on phase V3
V3 Frq1 %Un Maximum 1st signaling voltage magnitude on phase V3, %Un
V3 Frq2 %Un Maximum 2nd signaling voltage magnitude on phase V3, %Un
V3 Frq3 %Un Maximum 3rd signaling voltage magnitude on phase V3, %Un
V3 Frq4 %Un Maximum 4th signaling voltage magnitude on phase V3, %Un
Frq1 1st signaling voltage frequency
Frq2 2nd signaling voltage frequency
Frq3 3rd signaling voltage frequency
Frq4 4th signaling voltage frequency
EN50160 Harmonics Survey Log (Data Log #10)
Designation
THD MAX Maximum THD
THDO MAX Maximum odd harmonics THD
THDE MAX Maximum even harmonics THD
%HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
THD MAX Maximum THD
THDO MAX Maximum odd harmonics THD
THDE MAX Maximum even harmonics THD
Description
Mains Signaling Voltage
Description
V1 Harmonic Voltage
V2 Harmonic Voltage
