Appendix A Parameters for Monitoring and Logging
Designation
I1
I2
I3
I4
In
V ZERO-SEQ
I ZERO-SEQ
V UNB%
I UNB%
FREQ
V PSEQ
V ZSEQ UNB%
HRM TOT (0.2 sec)
V1 THD
V2 THD
V3 THD
I1 THD
I2 THD
I3 THD
I4 THD
V1 THD/I
V2 THD/I
V3 THD/I
I1 THD/I
I2 THD/I
I3 THD/I
I4 THD/I
I1 TDD
I2 TDD
I3 TDD
I4 TDD
I1 KF
I2 KF
I3 KF
I4 KF
HRM TOT (3 sec)
V1 THD
V2 THD
V3 THD
I1 THD
I2 THD
I3 THD
I4 THD
V1 THD/I
V2 THD/I
V3 THD/I
I1 THD/I
I2 THD/I
I3 THD/I
I4 THD/I
EM720 Power Quality and Revenue Meter
I1 current
I2 current
I3 current
I4 current
In current
Zero-sequence voltage
Zero-sequence current
Negative-sequence voltage unbalance
Negative-sequence current unbalance
Frequency
Positive-sequence voltage
Zero-sequence voltage unbalance
0.2-Second Total Harmonics
2
V1/V12 THD
2
V2/V23 THD
2
V3/V31 THD
I1 THD
I2 THD
I3 THD
I4 THD
V1/V12 interharmonics THD
V2/V23 interharmonics THD
V3/V31 interharmonics THD
I1 interharmonics THD
I2 interharmonics THD
I3 interharmonics THD
I4 interharmonics THD
I1 TDD
I2 TDD
I3 TDD
I4 TDD
I1 K-Factor
I2 K-Factor
I3 K-Factor
I4 K-Factor
3-Second Total Harmonics
2
V1/V12 THD
2
V2/V23 THD
2
V3/V31 THD
I1 THD
I2 THD
I3 THD
I4 THD
V1/V12 interharmonics THD
V2/V23 interharmonics THD
V3/V31 interharmonics THD
I1 interharmonics THD
I2 interharmonics THD
I3 interharmonics THD
I4 interharmonics THD
Description
2
2
2
2
2
2
