Appendix D EN50160 Statistics Log Files
Field No.
4
5
...
52
1
2
3
4
5
...
52
204
Designation
%HD02 MAX
Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX
Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX
Maximum H50 harmonic voltage magnitude, %Un
THD MAX
Maximum THD
THDO MAX
Maximum odd harmonics THD
THDE MAX
Maximum even harmonics THD
%HD02 MAX
Maximum H02 harmonic voltage magnitude, %Un
%HD03 MAX
Maximum H03 harmonic voltage magnitude, %Un
...
%HD50 MAX
Maximum H50 harmonic voltage magnitude, %Un
Description
V3 Harmonic Voltage
EM720 Power Quality and Revenue Meter
