Chapter 2 Operating the EM720

Operating the Fast Transient Recorder

Operating the Fault Recorder

Communicating with the EM720

EM720 Power Quality and Revenue Meter
currents while the event continues, using a variable recording
rate and variable averaging intervals.
See Configuring the EN50160 Recorders
EN50160 Evaluation and Recording
information on configuring and operating the PQ recorder.
The fast transient recorder is provided with EM720T meters.
It can detect impulsive and low frequency
transient overvoltages with peaks up to 2kV and durations
from 20 microseconds.
The recorder does not require any special setup above a
conventional PQ recorder setup for transient overvoltages.
Waveform log #3 is especially dedicated for fast transient
waveforms. It automatically
waveforms sampled
whenever a transient overvoltage is detected.
Unlike a basic transient recorder provided with the EM720
that detects and records transient voltages between phase
conductors and a neutral terminal (in 4LN3 and 3LN3
configurations), or between two phase conductors (in line-to-
line configurations), the fast transient recorder detects
transient voltages between phase conductors and a ground
terminal and between the neutral and a ground terminal
regardless of a wiring configuration.
See the EM720 Installation Manual for the terminal location
and wiring diagrams. To help you check your voltage
connections, the EM720 provides 1-cycle phase RMS voltages
V1x through V3x, and 1-cycle neutral voltage V4x relative to
the ground terminal, that you can monitor via PAS.
The programmable Fault recorder stores time-tagged fault
events into the fault event report. It can be triggered
externally through a digital input or internally from the
embedded fault detector.
The fault detector can automatically detect different fault
categories using the meter sub-cycle measurements. Fault
triggers have programmable thresholds and hysteresis and
can be adjusted for specific substation conditions.
The Fault recorder is programmable for triggering the
Waveform recorder to record fault voltage and current
waveforms before, within and after a fault event, and can
trigger the Data recorder for fast profiling of RMS voltages
and currents during a fault.
See Configuring the Fault Recorder
information on operation of the Fault recorder.
Communication with the EM720 is provided either via the
embedded optical
communication ports. See the EM720 Installation Manual for
Operating the Fast Transient Recorder
in Appendix E for more
stores
at a rate of
in Chapter 5 for more
IR port, or via
in Chapter 5 and
oscillatory
1-cycle voltage
1024 samples/cycle
the replaceable
25
