Chapter 7 Monitoring Meters
Printing Data
Real-time Data Logging

Viewing Real-time Min/Max Log

140
To check the report, as it will look when printed, select Print
Preview from the File menu.
To print retrieved data, click on the
toolbar, select a printer, and then click OK.
PAS allows you to store data records to a database
automatically at the time it updates data on the screen.
To setup the real-time logging options:
1. Open the Data Monitor window.
2. Click on the "RT Logging On/Off"
local toolbar, or select "RT Logging Options" from the
Monitor menu.
3. Select a database, or type the name for a new
database and select a directory where you want to
save it.
4. Select the number of tables, and the number of
records in each table you want recorded.
5. Adjust the file update rate for automatic recording. It
must be a multiple of the sampling rate that you
defined in the Instrument Setup dialog.
6. Click Save.
When you run real-time data polling, PAS automatically saves
retrieved records to a database at the rate you specified.
The "RT Logging On/Off" button
checked all the time. You can suspend logging by un-
checking the button, and then resume logging by checking it
again.
To retrieve the real-time Min/Max log data from your meter:
1. Select the device site from the list box on the PAS
toolbar.
2. Point to RT Min/Max Log on the Monitor menu, and
then select a data set you want to view.
3. Ensure that the On-line button
is checked.
4. Click on the Poll button
PAS supports 9 programmable data sets that you can
organize as you wish. To build your data sets, select MinMax
Data Sets from the Monitor menu or click on the
on the local toolbar.
See Working with Tables
on working with tables.
EM720 Power Quality and Revenue Meter
Viewing Real-time Min/Max Log
button on the PAS
button on the
on the toolbar should be
on the PAS toolbar
.
in Chapter 9 for more information
button
