Appendix A Parameters for Monitoring and Logging
Designation
PF LEAD
kW IMP
kW EXP
kvar IMP
kvar EXP
V AVG
V LL AVG
I AVG
RT AUX
I4
In
FREQ
V UNB%
I UNB%
AVR PHASE
V1
V2
V3
I1
I2
I3
kW L1
kW L2
kW L3
kvar L1
kvar L2
kvar L3
kVA L1
kVA L2
kVA L3
PF L1
PF L2
PF L3
V1 THD
V2 THD
V3 THD
I1 THD
I2 THD
I3 THD
I1 KF
I2 KF
I3 KF
I1 TDD
I2 TDD
I3 TDD
V12
V23
V31
V1x
178
8
Total PF lead
8
Total kW import
8
Total kW export
8
Total kvar import
8
Total kvar export
3-phase average line-to-neutral/line-to-line voltage
3-phase average line-to-line voltage
3-phase average current
1-Cycle Auxiliary Values
I4 current
In current
Frequency
6
Voltage unbalance
6
Current unbalance
1-Second Phase Values
1
V1/V12 voltage
1
V2/V23 voltage
1
V3/V31 voltage
I1 current
I2 current
I3 current
kW L1
kW L2
kW L3
kvar L1
kvar L2
kvar L3
kVA L1
kVA L2
kVA L3
Power factor L1
Power factor L2
Power factor L3
2,4
V1/V12 Voltage THD
2,4
V2/V23 Voltage THD
2,4
V3/V31 Voltage THD
4
I1 Current THD
4
I2 Current THD
4
I3 Current THD
4
I1 K-Factor
4
I2 K-Factor
4
I3 K-Factor
4
I1 Current TDD
4
I2 Current TDD
4
I3 Current TDD
V12 Voltage
V23 Voltage
V31 Voltage
V1x phase-to-ground voltage
