Chapter 5 Configuring the EM720

Chapter 5 Configuring the EM720

Configuring Communications

Setting Up Serial Communication Ports

60
This chapter describes how to configure the EM720 for your
particular environment and application from the front display
and via PAS. To access your meter configuration options via
PAS, you should create a site database for your device as
shown in Chapter 4.
Using the Front Display
Select COM1 through COM3 from the main menu. See
Viewing and Changing Setup Options
information on navigating in menus.
See the table below for available communication options.
Using PAS
Select Communications Setup from the Meter Setup menu,
and then click on the Serial Ports Setup tab. In the Port box,
select the desired device port.
To change the port settings in your device, select desired port
parameters, and then click Send.
The following table lists available port options.
EM720 Power Quality and Revenue Meter
Configuring Communications
in Chapter 3 for
