Chapter 5 Configuring the EM720

General Meter Setup

Basic Meter Setup

Display Label
Wiring
PT Ratio
68
The Basic Setup provides the meter with basic information
about your electrical network.
Using the Front Display
Select Basic from the main menu. See
Setup Options
menus.
See the table below for available options.
Using Pas
Select General Setup from the Meter Setup menu.
The following table lists available meter configuration options.
Parameter
Basic Configuration
Wiring Mode See Table
below
1
1.0-6500.0
PT Ratio
in Chapter 3 for information on navigating in
Options Default
4LN3
1.0
EM720 Power Quality and Revenue Meter
General Meter Setup
Viewing and Changing
Description
The wiring connection of the
device
The phase potential
transformer's primary to
secondary ratio
