Satec expertmeter EM720 Operation Manual page 13

Chapter 1 Introduction
EM720 Models
Supplemental Documents
Meter Nameplate
MAC address
Voltage input
Rated current
EM720 Power Quality and Revenue Meter
The EM720 meter series includes two models:
• EM720 – basic model - offers all the EM720 billing,
instrumentation, control, power quality and fault
recording capabilities
• EM720T – fast transient model - adds to above a fast
transient recorder with a capability of detecting
transient overvoltages with peaks up to 2kV and
durations of less than 20 microseconds
See the EM720 Installation Manual for technical specifications
and ordering options.
BG0450 EM720 Installation Manual
BG0457 EM720 Modbus Reference Guide
BG0458 EM720 DNP3 Reference Guide
BG0460 EM720 IEC 62056-21 Reference Guide
BG0459 EM720 IEC 61850 Reference Guide
BG0337 PAS Getting Started Guide
Watt-hour meter constant
Meter serial number
13
