Chapter 4 Using PAS Software

Setting Up the Meter

EM720 Power Quality and Revenue Meter
PAS allows you to prepare setup data for your meter off-line
without the need to have it connected to your PC.
To prepare a setup for your meter:
1. Select the device site from the list box on the PAS
toolbar.
2. Select the desired setup group from the Meter Setup
menu. Click on the tab with the setup you want to
create or modify.
3. Fill in the boxes with the desired configuration data for
your meter.
4. Click the "Save as..." button to store the data to the
meter site database.
5. Click OK.
NOTE
Always set up and store the Basic Setup data to the site
database first. PAS uses this data as a reference when
arranging other meter setups.
To save your setup to another site database:
1. Click the "Save as..." button.
2. Select the target database from the file pane.
3. Click OK.
You can also reuse a setup from another site by copying it to
your present site database.
To copy a setup from another site's database:
1. Click Open.
2. Select the desired source site database.
3. Click OK. The opened setup is copied to your dialog
window.
4. Click the "Save as..." button.
5. Select the target database from the file pane.
6. Click OK.
To copy all setups from one site database to another
site's database:
1. In the list box on the toolbar, select a source device
site from which you wish to copy setups.
2. Select "Copy to..." from the Meter Setup menu.
3. Select the target site database to which you wish to
copy setups, and click OK.
Setting Up the Meter
