Chapter 5 Configuring the EM720
XPW Server IP Address
XPW Server Port
XPW Client Enabled
Time to Next Session,
min
Connection via Network

Setting-Up TCP Notification Client

66
Parameter
0-65535
NO, YES
1-99999
Ethernet,
GPRS/Modem
NOTES
1. Do not enable the eXpertPower client in your meter if
you do not use the eXpertPower
2. Do not change the connection period setting. The
eXpertPower server updates it automatically.
Select Communication Setup from the Meter Setup menu,
and then click on the TCP Notification Client Setup tab.
The TCP notification client can establish connections with a
remote Modbus/TCP server and send notification messages
either on events, or periodically on a time basis. See the
EM720 Modbus Reference Guide for more information on the
client operation and the notification message layout.
The server's IP address, port number and starting Modbus
register address are programmable in the meter.
Configuring Communications
Options Default
207.232.60.18
5001
NO
Ethernet
EM720 Power Quality and Revenue Meter
Description
The IP address of the
eXpertPower server
The TCP service port of the
eXpertPower server
Enables operations of the
eXpertPower client
The time remaining to the
next connection session
Selects the network for
connecting to the
eXpertPower server
TM
service.
